CYBERPOWER GreenPower UPS Line-Interactive 700VA/390W 6xIEC C13 || VP700EILCD

Product Description

CyberPower VP700EILCD. UPS topology: Line-Interactive, Output power capacity: 0.7 kVA, Output power: 390 W. AC outlet types: C13 coupler, AC outlets quantity: 6 AC outlet(s), Cabling technology: 10/100/1000Base-T(X). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 1 min, Typical backup time at half load: 10 min. Form factor: Tower, Product colour: Black, Housing material: Plastic. Compliance certificates: RoHS, Certification: CE, EAC

Features:

• Line-interactive UPS Topology
• Energy Saving Technology
• Generator Compatible
• Simulated Sine Wave Output
• Automatic Voltage Regulation (AVR)
• LCD Status Display
• High-speed Ethernet Data Transmission
• USB Connectivity Port
• Surge and Spike Protection
• Serial Connectivity Port
• PowerPanel® Management Software

Specifications:

UPS topology  UPS topology: Line-Interactive
Output power capacity  Output power capacity: 0.7 kVA
Output power  Output power: 390 W
Waveform : Sine
Input operation voltage (min)  Input operation voltage (min): 167 V
Input operation voltage (max)  Input operation voltage (max): 295 V
Input frequency  Input frequency: 50/60 Hz
Output operation voltage (min)  Output operation voltage (min): 230 V
Output operation voltage (max)  Output operation voltage (max): 230 V
Output frequency : 50/60 Hz
Automatic Voltage Regulation (AVR) : Yes
Maximum current  Maximum current: 3.04 A
Surge energy rating  Surge energy rating; 450 J
Response time  Response time: 4 ms
EMI/RFI noise filtering : Yes
Surge protection : Yes
Audible alarm(s)  Audible alarm(s): Yes
Audible alarm modes : Fault, Low battery alarm, Overload alarm

Ports & interfaces
AC outlet types: C13 coupler
AC outlets quantity: 6 AC outlet(s)
USB port  USB port: Yes
Serial interface : Yes
Modem (RJ-11) ports : 1
Ethernet LAN (RJ-45) ports  Ethernet LAN (RJ-45) ports: 1
Cabling technology: 10/100/1000Base-T(X)

Battery
Battery technology: Sealed Lead Acid (VRLA)
Typical backup time at full load: 1 min
Typical backup time at half load: 10 min

Design
Housing material: Plastic
Form factor  Form factor: Tower
Product colour  Product colour: Black
Display type  Display type: LCD
LED indicators : Operation

Operational conditions
Operating temperature (T-T) : 0 - 40 °C
Storage temperature (T-T) : -20 - 50 °C
Operating relative humidity (H-H) : 0 - 90%
Storage relative humidity (H-H) : 0 - 90%
Operating altitude : 0 - 3000 m
Non-operating altitude : 0 - 3000 m

Packaging content
Cables included : USB cable

Certificates
Compliance certificates : RoHS
Certification : CE, EAC

Weight & dimensions
Width : 100 mm
Depth: 260 mm
Height: 227 mm
Weight: 5.14 kg

Packaging data
Package width:300 mm
Package depth :143 mm
Package height :335 mm
Package weight:5.8 kg
